Appendix ? B: ? Development ? Guide
Development Kit Contents
The 9XTend Development Kit includes the hardware and software needed to rapidly create long
range wireless links between devices.
Table ? B ‐ 01. XTend ? Development ? Kit ? Contents
Item
XTend OEM RF Module
XTend OEM RF Module
Antenna
Antenna
RS-232 Interface Board
RS-232 Cable (6')
Serial Loopback Adapter
NULL Modem Adapter
(male-to-male)
NULL Modem Adapter
(female-to-female)
Male DB-9 to RJ-45
Adapter
Female DB-9 to RJ-45
Adapter
Power Adapter
CD
Quick Start Guide
Qty.
1
1
1
1
2
2
1
1
1
1
1
2
1
1
Description
Long Range 900 MHz RF Module (w/ RPSMA Connector)
Long Range 900 MHz RF Module (w/ MMCX antenna)
900 MHz RPSMA, 6" Half-Wave, dipole, articulating, RPSMA
900 MHz RPSMA, 7" Half-Wave, dipole, articulating, w/ pigtail, MMCX
Enables communication to RS-232 devices
Connects interface board to devices having an RS-232 serial port
Connects to the female RS-232 (DB-9) serial connector of the
MaxStream Interface Board and can be used to configure the module
to function as a repeater (for range testing)
Connects to the female RS-232 (DB-9) serial connector of the
MaxStream Interface Board and can be used to connect the module to
another DCE (female DB9) device
Used to bypass radios to verify serial cabling is functioning properly
Facilitates adapting the DB-9 Connector of the MaxStream Interface
Board to a CAT5 cable (male DB9 to female RJ45)
Facilitates adapting the DB-9 Connector of the MaxStream Interface
Board to a CAT5 cable (female DB9 to female RJ45)
Allows Interface Board to be powered by a 110 Volt AC power supply
(not included with international (-INT) development kits)
Contains documentation, software and tools needed for RF operation.
Familiarizes users with some of the module's most important functions.
Part Number
XT09-SI
XT09-MI
A09-HASM-675
A09-HABMM-P5I
XTIB-R
JD2D3-CDS-6F
JD2D3-CDL-A
JD2D2-CDN-A
JD3D3-CDN-A
JE1D2-CDA-A
JE1D3-CDA-A
JP4P2-9V10-6F
MD0010
MD0016
Interfacing Hardware
The XTend Development Kit includes a pair of RS-232 interface boards that supports the RS-232/
485/422 protocols. When the modules are mounted to the interface boards, the boards provide
the following development tools:
? Fast and direct connection to serial devices (such as PCs) and therefore easy access to the
module registries - The parameters stored in the registry allow OEMs and integrators to cus-
tomize the modules to suite the specific needs of their data systems.
? External DIP switch for automatic configuration of commonly used module profiles
? Conversion of signals between TTL levels and RS-232 levels
The MaxStream Interface board provides means for connecting the module to any device that has
an available RS-232 or RS-485/422 connection. The following sections illustrate how to use the
interface boards for development purposes.
Note: In the sections the follow, an OEM RF module mounted to an interface board will be referred to
as a "Module Assembly".
? ? 2007 ? MaxStream, ? Inc.
????? 59
